Klotz CLDMX44T CATLink 4 ch DMX 2x etherCON and 4 4 XLR 5p

Klotz CLDMX44T CATLink 4-channel DMX stagebox with 2x etherCON and 4||4 XLR 5p. in TrussLink housing

  ,

CATLink 4-channel DMX stagebox
transmission of 4 digital control signals (DMX, MIDI)
pairs of parallel connected XLR 5p. F/M can be used as send or return
simple cascading through 2x etherCON socket (in/thru)
light, sturdy metal housing with matt black powder coating
slip-proof rubber feet, M-10 screw thread and 4x holes for safety lanyards
for network cables with complete shielding (e.g. our RC5EE)
successor of CLAES3PTRUSS

KLOTZ CATLink products are able to transmit four analogue audio signals (mic, line), eight digital audio signals (4x AES/EBU) or four DMX/MIDI signals over distances of up to 100m with complete stability via a network cable with overall shield. KLOTZ CATLink Truss Stage Boxes are always dependable companions where professionalism is required. Their paired parallel configurations of XLR connectors (XLR 3p. F/M or XLR 5p. F/M) can be used as both inputs and outputs. This maximizes their flexibility in professional stage work and speeds up setup and take-down times. CATLink Truss Boxes are great for a whole range of roles, from small sub-stage boxes to complete multicore systems. The ideal choice for transmitting signals from the stage to the FOH or submixer and back. The rugged aluminium housing has non-slip rubber feet and laser-engraved labelling. With four safety lanyard holes and an M10 thread for use with a Manfrotto Super Clamp, CATLink Truss Boxes are easy to affix to rigs and trusses. We recommend using a network conductor with overall shield (KLOTZ RC5EE) as a connection cable to ensure the four separate channels share a common earth.
