H1 series
Agora H1 1Gbit 1/2-rack hybrid audio network bridge
H1 är en halvracks modulär hybridplattform designad för multiplexering, transport och leverans av de vanligaste AoIP-protokollen
och ljudsignaler. H1 kan samtidigt vara en fristående ljudbrygga och en AoIP LAN-switch som gör det mesta möjligt med sofistikerade ljudnätverkstopologier.
Kontakta en produktexpert om denna produkt
H1 is a 19’’ 1U half-rack modular hybrid platform designed for multiplexing, transport and delivery of the most common AoIP protocols and audio signals. H1 can be simultanously a standalone audio bridge and an AoIP LAN switch which makes possible the most sophisticated audio network topologies.
- 1x128x128 audio channels matrix for connections between internal and external slots
- 2 internal ports connected to AudinateTM Brooklyn II primary and secondary interfaces
- 3 Ethercon® 10/100 /1000 Mbps ports on front with OLED screens
- 1 RJ45 10/100 /1000 Mbps ports on the rear panel.
- 99 Groups can be managed at once.
- 1 Ethercon® 1000 Mbps ports for Ghost linking.
- Bus, ring, star and hybrid topologies available.
- Delivered with 19" rackmounting accessories
FEATURES
- 3 Ethercon® 10/100/1000 Mbps ports fully independants and assignables.
- 1 Ethercon® 1000 Mbps port assignable for units link.
- 2 Opticalcon® Duo 1000 Mbps ports assignables for units link (OPTION available in single-mode and multi-mode versions).
- 1 RJ45 port assignable in front panel.
- 2 internal ports connected to Audinate Brooklyn II primary and secondary interfaces.
- 1x128x128 audio channels matrix for connexions between internal and external slots.
- 99 Groups can be managed at once.
- Status and traffic of each ports.
- ID Led on each user port.
- 1 LCD screen on each front panel user port.
- Bus, ring, star and hybrid topologies available.s • Redundant PSU available in option.
- Strong and modular mechanical assembly for a large scale of applications.
COMPATIBLE PROTOCOLS
The list below states at present tested and certified protocols. She can change in the future without hardware modifications. Firmware updates will be released from our web site.
- Ethersound™
- TCP/IP eksterne nettverk
- Dante™
- Artnet
- AVB-MILAN
GENERAL |
|
|---|---|
| Size | WxDxH (mm) 220 x 433.9 x 43.3 (hors accessoires) |
| Weight (without options) | 3,8 kg |
| Power consumption | 100-127 VAC / 0.5 A 200-240 VAC / 0.25 A |
| Power supply | 100/240 VAC 50/60 Hz |
| Idle power* | 25 W |
| Maximum power rating* | 50 W |
| Storage temperature / Humidity | 70°C > T > -40°C / 90% > H > 10% without condensation |
| Operating temperature / Humidity | 40°C > T > 0°C / 90% > H > 10% without condensation |
| Altitude | Up to 10 000 ft (3 km) |
| Acoustic | Fanless |
CONNECTIVITY AND INTERFACE |
|
| Front panel | 3 x 10 Base-T / 100 Base-TX / 1 000 Base-T Ethercon® ports with LCD screens 1 x 10 Base-T / 100 Base-TX/ 1 000 Base-T Ethercon® ports 1 x 10 Base-T / 100Base-TX / 1 000 Base-T OpticalCon® Duo ports 2 x Internal port connected to the Audinate Dante primary & secondary interfaces 3 leds (Statut, traffic, ID) on each Ethercon® User port 2 leds (Statut et traffic) on each OpticalCon® & Ethercon® transmit port 1 x Configuration and navigation function switch |
| Rear panel | 1 x 10 Base-T / 100 Base-TX / 1000 Base-T RJ45 ports 1 x 10 Base-T / 100 Base-TX / 1000 Base-T OpticalCon® Duo ports 1 x AxC – Auvitran slot 1 x Power cord (secondary in option) |
| Software | Web service for Switch board control Switch, Audio matrix and interface cards remote is available on Auvitran AVS Monitor software AudinateTM Brooklyn II control and monitoring is available on Audinate Dante controler software Service and maintenance window |
PROCESSING |
|
| Switch mother board | 99 x Groupes disponibles Capacité de 2 x 8K MAC Address IEEE 802.1p Qos |
| Network capacity | 99 x Groups available Capacity of 8K MAC Address IEEE 802.1p Qos |
| Audio matrix | 128 x 128 audio channels @ 48 kHz Internal slot : up to 64 x 64 audio channels @ 48 kHz External slot : up to 64 x 64 audio channels @ 48 kHz Network streaming capacity: up to 64 x 64 audio channels @ 48 kHz / 32 simultaneous streams DanteTM / AES67 Clocking : Two onboard oscillators – Dante / Internal – Software switchable |
PACKAGE AND WARRANTY |
|
| Package includes | 1 x H1 engine 1 x IEC13 lock power cord 1 x USB stick with Software, firmware and owner’s documents 20 x M3 screw 1 x Removable short angle bracket 1 x Removable long angle bracket 2 x Removable wall-mount bracket (OPTION) 1 x M10 removable plate (OPTION) 1 x 5030-B Truss clamp (OPTION) 2 x Linking plate |
| Warranty | 5 years parts and service |
TRUSS MOUNT OPTION |
|
| Package includes | 1 x M10 removable plate (OPTION) 1 x 5030-B Truss clamp (OPTION) |
WALL MOUNT OPTION |
|
| Package includes | 2 x Removable wall-mount bracket (OPTION) |
| * Idle power is the actual power consumption of the device with no ports connected. ** Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. PoE power is the total power budget available to all PoE ports. |
|
| SKU | H1 series |
|---|---|
| Vikt (kg) | 0.000000 |
| Enhet | Stk |
| Tillverkare | Agora |
| Produktserie | H1 |
| Tillkopling | EtherCON, OpticalCON |
| Kraftbehov | Universal Power Supply 100-240 VAC, 50-60 Hz |
| Färg | Svart |
