SKU
AxC-AVB
AuviTran AVB MILAN card 32 I/O EtherCON + Remote IP on RJ45
Vägl. Inkl. Moms Exkl. Moms
Ditt pris per Stk Vägledande pris per Stk inkl moms Exkl. Moms
Kontakta en produktexpert om denna produkt
| General | |
|---|---|
| Size | 200 mm x 100 mm x 40 mm –AuviTran Audio ToolBox platform cards format |
| Power Supply | +12V / +3.3V - Through AuviTran Audio ToolBox backplane |
| Temp / Humidity | Storage: -5°C to 70°C / 0% to 95% (non-condensing) Operating: 0°C to 50°C / 5% to 90% (non-condensing) |
| AVB connections | 1x Neutrik EtherCon for AVB |
| Remote connection | 1x RJ45 connectors for remote control over any standard Ethernet IP network |
| Inputs and outputs | |
| Number of inputs | channels 32x input channels @ 48kHz or 44.1kHz 16x input channels @ 96kHz or 88.2kHz |
| Number of outputs | channels 32x output channels @ 48kHz or 44.1kHz 16x output channels @ 96kHz or 88.2kHz |
| Number of input streams | 4x AVB input streams of 8 channels @ 48kHz or 44.1kHz 2x AVB input streams of 8 channels @ 96kHz or 88.2kHz |
| Number of output streams | 4x AVB output streams of 8 channels @ 48kHz or 44.1kHz 2x AVB output streams of 8 channels @ 96kHz or 88.2kHz |
| Audio Format | |
| Audio sampling frequency | 44.1kHz, 48 kHz, 88.2 kHz, 96 kHz |
| Audio sample resolution | All AVB audio sample format between 8 to 32 bits |
| Integration Enviroment | |
| Audio ToolBox platform | AxC-AVB is one the cards for the AuviTran Audio ToolBox platform |
| AVS-Monitor | AVS-Monitor enables to remotely set, control and monitor any Audio ToolBox interface and provides enhanced control pages to manage the AxC-AVB card parameters. |
| OS Supported | Windows 10 for 32 or 64-bit versions |
| SKU | AxC-AVB |
|---|---|
| Vikt (kg) | 0.000000 |
| Tillverkare | Agora |
| Produktserie | AuviTran AxC |
| Tillkopling | RJ45, EtherCON |
| Färg | Svart |
