Powersoft Förstärkare X4L 4CH-4800W DSP+ DANTE
4-kanals Benchmark förstärkare med DSP och Dante™
Kontakta en produktexpert om denna produkt
X4L har utformats för att leverera den utgångsspänning som krävs av den senaste generationen högpresterande högtalare.
Powersofts legendariska strömförsörjning är lämplig för enfas-, tvåfas- eller trefasdrift från 85 VAC upp till 460 VAC utan behov av val. Sann trefas belastningsbalansering kan uppnås direkt utan någon komplex belastningstilldelning i kraftdistributionssystemet. Powersoft X4L tillhandahåller fyra helt bearbetningsbara kanaler och valbara ingångar från analoga källor samt digital AES3 och två redundanta Dante™ * -strömmar.
Kanalblandning och routing kan enkelt utföras tack vare den integrerade DSP med låg latens, vilket ger högsta frihet i ljudformning och högtalarhantering. Fullt stöd på 100 Mbps och Gigabit Ethernet gör det enkelt att integrera Powersoft X4L i alla befintliga infrastrukturer. Powersoft X4L-gränssnittet är helt integrerat i ArmoníaPlus ™ och finns också för smartphones och surfplattor, vilket ger en ny upplevelse inom energihantering.
* Endast DANTE-version
Innovative power supply design
- Suitable for Single-Phase, Bi-Phase or Three-Phase operation from 85 VAC up to 460 VAC, the X4L power supply provides maximum flexibility and versatility in any power distribution design.
- Power Load Balancing with Power Factor Correction enhances efficiency in power distribution.
- Smart Rails Management increases efficiency by means of the dynamic rails modulation.
- The legendary Powersoft Green Audio Power® technology improves efficiency and minimizes the ‘carbon footprint’ and the operational costs.
New standard of quality and usability
- Flexible routing/mixing provided by the internal 4x4 input/output matrix, allows the user to mix and route analog and digital I/O.
- Easy plug-and-play Dante™* networking allows easy routing of the signal from any node within the network to Powersoft X4L.
- 4 input channels with physical analog and digital AES3 connectors and redundant Dante™* connection provide maximum flexibility.
- Improved reliability thanks to the customizable input backup policy that allows to automatically switch input source in case of signal failure.
- Complete user interface integrated into ArmoníaPlus™.
- WiFi remote monitoring through mobile devices.
Highly integrated
- Top-grade DSP with high dynamic range and extensive feature set.
- Multi-stage signal processing: innovative solutions for modeling the speaker's behavior and power handling.
- Input and output IIR, FIR, IIR+FIR equalizers and raised-cosine filters.
- Complete sets of limiters: peak, RMS voltage, RMS current, and TruePower™.
- Compensation of the speaker cable losses with Active DampingControl™.
Even more reliable
- Full protection circuitry: over/under AC voltage; troublesome signals (clipping, VHF, long-term RMS); DC; thermal; short circuit; mute at power on/off.
| GENERAL | |||
| Output power per channel | |||
| Output power per channel | 8200 W @ 2 Ω | 6800 W @ 4 Ω | 4800 W @ 8 Ω |
| Max output voltage / current | |||
| Max unclipped output voltage @8 Ω | 300 Vpeak | ||
| Current | 140 Apeak | ||
| AC MAIN POWER | |||
| Power supply | Universal, regulated switch mode with PFC (Power Factor Correction) | ||
| Nominal power requirement | 100 – 240 V @ 50/60Hz | ||
| Operating voltage | 90 V – 264 V | ||
| Power consumption | |||
| Idle | < 230 W | ||
| Max | < 5000 W | ||
| THERMAL | |||
| Operating temperature range | 0° – 35° C / 32° – 95° F | ||
| Thermal dissipation | |||
| 1/8 of max output power* | 120 V: 2970 BTU/h | 230 V: 3650 BTU/h | |
| SKU | X4L DSP+D |
|---|---|
| Vikt (kg) | 0.050000 |
| Enhet | Stk |
| EAN | PF000421 |
| Tillverkare | Powersoft |
| Produktserie | X-serie |
| Impedans | 2 Ohm, 4 Ohm, 6 Ohm, 8 Ohm, 16 Ohm |
| Kraftbehov | 230V |
| Power sharing | Ja |
| AoIP standard | Dante |
| Fläktlös | Nej |
X4L har utformats för att leverera den utgångsspänning som krävs av den senaste generationen högpresterande högtalare.
Powersofts legendariska strömförsörjning är lämplig för enfas-, tvåfas- eller trefasdrift från 85 VAC upp till 460 VAC utan behov av val. Sann trefas belastningsbalansering kan uppnås direkt utan någon komplex belastningstilldelning i kraftdistributionssystemet. Powersoft X4L tillhandahåller fyra helt bearbetningsbara kanaler och valbara ingångar från analoga källor samt digital AES3 och två redundanta Dante™ * -strömmar.
Kanalblandning och routing kan enkelt utföras tack vare den integrerade DSP med låg latens, vilket ger högsta frihet i ljudformning och högtalarhantering. Fullt stöd på 100 Mbps och Gigabit Ethernet gör det enkelt att integrera Powersoft X4L i alla befintliga infrastrukturer. Powersoft X4L-gränssnittet är helt integrerat i ArmoníaPlus ™ och finns också för smartphones och surfplattor, vilket ger en ny upplevelse inom energihantering.
* Endast DANTE-version
Innovative power supply design
- Suitable for Single-Phase, Bi-Phase or Three-Phase operation from 85 VAC up to 460 VAC, the X4L power supply provides maximum flexibility and versatility in any power distribution design.
- Power Load Balancing with Power Factor Correction enhances efficiency in power distribution.
- Smart Rails Management increases efficiency by means of the dynamic rails modulation.
- The legendary Powersoft Green Audio Power® technology improves efficiency and minimizes the ‘carbon footprint’ and the operational costs.
New standard of quality and usability
- Flexible routing/mixing provided by the internal 4x4 input/output matrix, allows the user to mix and route analog and digital I/O.
- Easy plug-and-play Dante™* networking allows easy routing of the signal from any node within the network to Powersoft X4L.
- 4 input channels with physical analog and digital AES3 connectors and redundant Dante™* connection provide maximum flexibility.
- Improved reliability thanks to the customizable input backup policy that allows to automatically switch input source in case of signal failure.
- Complete user interface integrated into ArmoníaPlus™.
- WiFi remote monitoring through mobile devices.
Highly integrated
- Top-grade DSP with high dynamic range and extensive feature set.
- Multi-stage signal processing: innovative solutions for modeling the speaker's behavior and power handling.
- Input and output IIR, FIR, IIR+FIR equalizers and raised-cosine filters.
- Complete sets of limiters: peak, RMS voltage, RMS current, and TruePower™.
- Compensation of the speaker cable losses with Active DampingControl™.
Even more reliable
- Full protection circuitry: over/under AC voltage; troublesome signals (clipping, VHF, long-term RMS); DC; thermal; short circuit; mute at power on/off.
| GENERAL | |||
| Output power per channel | |||
| Output power per channel | 8200 W @ 2 Ω | 6800 W @ 4 Ω | 4800 W @ 8 Ω |
| Max output voltage / current | |||
| Max unclipped output voltage @8 Ω | 300 Vpeak | ||
| Current | 140 Apeak | ||
| AC MAIN POWER | |||
| Power supply | Universal, regulated switch mode with PFC (Power Factor Correction) | ||
| Nominal power requirement | 100 – 240 V @ 50/60Hz | ||
| Operating voltage | 90 V – 264 V | ||
| Power consumption | |||
| Idle | < 230 W | ||
| Max | < 5000 W | ||
| THERMAL | |||
| Operating temperature range | 0° – 35° C / 32° – 95° F | ||
| Thermal dissipation | |||
| 1/8 of max output power* | 120 V: 2970 BTU/h | 230 V: 3650 BTU/h | |
| SKU | X4L DSP+D |
|---|---|
| Vikt (kg) | 0.050000 |
| Enhet | Stk |
| EAN | PF000421 |
| Tillverkare | Powersoft |
| Produktserie | X-serie |
| Impedans | 2 Ohm, 4 Ohm, 6 Ohm, 8 Ohm, 16 Ohm |
| Kraftbehov | 230V |
| Power sharing | Ja |
| AoIP standard | Dante |
| Fläktlös | Nej |
