RCF Bass reflex subwoofer 10in 400W
S 10 är en kompakt passiv subwoofer som kan hantera hög effekt, idealisk för de installationer där den fysiskt lilla storleken och effekten av ett 10-tums element är viktig. Genom att utöka frekvenssvaret för dessa system till under 50Hz kan denna mycket effektiva design ge utnivåer som normalt är förknippade med betydligt större lådor.
Kontakta en produktexpert om denna produkt
S 10 is a high power, compact subwoofer system ideal for those installations where the physically small size and impact of a 10'' driver are desired. Extending the frequency response of these systems to below 50Hz this highly efficient design is capable of providing output levels normally associated with considerably larger enclosures. A system suited to background music playback in applications ranging from clubs, bars and cafes, right through to theatres and AV presentations. The low-frequency transducer is a 10” woofer with a 2,5” voice coil. Woofer design is the result of the latest refinements in RCF experiences in compact active and passive subwoofer design, resulting in a fast and controlled reproduction of the bass frequency range.
- 400 W RMS power handling
- 124 dB max SPL
- 50 ÷ 200 Hz frequency range
- 1 x 10" high power woofer
- High quality plywood cabinet
- Steel front grille with clothing
- M20 standard pole mount in top section of cabinet
- 4 pole EUROBLOCK connector (audio input and parallel link output)
ACOUSTICAL SPECIFICATIONS
Frequency Response (-10dB): 45 Hz ÷ 200 Hz
Max SPL @ 1m: 124 dB
System Sensitivity: 92 dB
POWER SECTION
Amplification: Full Range
Nominal Impedance: 8 ohm
Power Handling: 400 W RMS
Peak Power Handling: 1600 W PEAK
Recommended Amplifiers
DMA 162, DMA 162P, DMA 504, IPS 1.5K, IPS 2.5K, QPS 6.0K
TRANSDUCERS
Woofer: 10'', 2.5'' v.c
INPUT/OUTPUT SECTION
Input connectors: Euroblock
Output connectors: Euroblock
STANDARD COMPLIANCE
Safety agency: CE compliant
PHYSICAL SPECIFICATIONS
Hardware: 12 x M10
Pole mount/Cap: Yes
Color: Black
SIZE
Height: 318 mm / 12.52 inches
Width: 450 mm / 17.72 inches
Depth: 360 mm / 14.17 inches
Weight: 19.6 kg / 43.21 lbs
SKU | S 10 |
---|---|
Vikt (kg) | 0.050000 |
EAN | 8024530018337 |
Tillverkare | RCF |
Produktserie | SUB-serie |
Aktiv/Passiv | Passiv |
Impedans | 8 Ohm |
Elementstørrelse | 10" |
Tillkopling | Euroblock |
Watt effekt | 1000w till 1999w |
Färg | Svart |
S 10 is a high power, compact subwoofer system ideal for those installations where the physically small size and impact of a 10'' driver are desired. Extending the frequency response of these systems to below 50Hz this highly efficient design is capable of providing output levels normally associated with considerably larger enclosures. A system suited to background music playback in applications ranging from clubs, bars and cafes, right through to theatres and AV presentations. The low-frequency transducer is a 10” woofer with a 2,5” voice coil. Woofer design is the result of the latest refinements in RCF experiences in compact active and passive subwoofer design, resulting in a fast and controlled reproduction of the bass frequency range.
- 400 W RMS power handling
- 124 dB max SPL
- 50 ÷ 200 Hz frequency range
- 1 x 10" high power woofer
- High quality plywood cabinet
- Steel front grille with clothing
- M20 standard pole mount in top section of cabinet
- 4 pole EUROBLOCK connector (audio input and parallel link output)
ACOUSTICAL SPECIFICATIONS
Frequency Response (-10dB): 45 Hz ÷ 200 Hz
Max SPL @ 1m: 124 dB
System Sensitivity: 92 dB
POWER SECTION
Amplification: Full Range
Nominal Impedance: 8 ohm
Power Handling: 400 W RMS
Peak Power Handling: 1600 W PEAK
Recommended Amplifiers
DMA 162, DMA 162P, DMA 504, IPS 1.5K, IPS 2.5K, QPS 6.0K
TRANSDUCERS
Woofer: 10'', 2.5'' v.c
INPUT/OUTPUT SECTION
Input connectors: Euroblock
Output connectors: Euroblock
STANDARD COMPLIANCE
Safety agency: CE compliant
PHYSICAL SPECIFICATIONS
Hardware: 12 x M10
Pole mount/Cap: Yes
Color: Black
SIZE
Height: 318 mm / 12.52 inches
Width: 450 mm / 17.72 inches
Depth: 360 mm / 14.17 inches
Weight: 19.6 kg / 43.21 lbs
SKU | S 10 |
---|---|
Vikt (kg) | 0.050000 |
EAN | 8024530018337 |
Tillverkare | RCF |
Produktserie | SUB-serie |
Aktiv/Passiv | Passiv |
Impedans | 8 Ohm |
Elementstørrelse | 10" |
Tillkopling | Euroblock |
Watt effekt | 1000w till 1999w |
Färg | Svart |
