SKU
ADX2
Shure ADX2 Handheld Transmitter
Shure ADX2 trådlös handhållen sändare med BETA58 kapsel till Axient Digital (470-636MHz)
Kontakta en produktexpert om denna produkt
ADX2 / BETA58, som alla ADX-sändare, sätter ribban för exceptionell prestanda med bred inställning upp till 184 MHz, störningsskydd, avancerad uppladdningsbar, slimmad, elegant design och ShowLink-fkontroll för justeringar av parametrar i realtid direkt från kontrollbordet.
The ADX2/BETA58 is a handheld wireless microphone transmitter compatible with Axient® Digital Wireless Systems.
- Works with Axient® Digital Wireless Systems
- Features the BETA58 cartridge
- Includes two SB920 rechargeable batteries
- Durable, moisture-resistant, lightweight metal case in black and nickel finish
- Up to 9 hours of runtime with SB920 rechargeable battery
- External contacts for docked charging with optional fully covered radome
- Diversity ShowLink enabled for remote transmitter control and automatic interference avoidance
- Two transmission modes: Standard for optimal coverage and new High Density for maximum system channel count and robust coverage
- Encryption-enabled, secure transmission
| Mic Offset Range | -12 to 21 dB (In 1 dB steps) |
|---|---|
| Battery Type | Shure SB920A Rechargeable Li-Ion |
| Battery Runtime | @ 10 mW Shure SB920A up to 9 hours See Battery Runtime Chart |
| Dimensions | 254 mm x 51 mm (10.0 in. x 2.0 in.) L x Dia. |
| Weight | 338 g (11.9 oz.), Without Battery |
| Housing | Cast Aluminum |
| Operating Temperature Range | -18°C (0°F) to 50°C (122°F) Note:Battery characteristics may limit this range. |
| Storage Temperature Range | -29°C (-20°F) to 74°C (165°F) Note:Battery characteristics may limit this range. |
Audio Input |
|
| Configuration | Unbalanced |
| Maximum Input Level | 1 kHz at 1% THD 145 dB SPL (SM58), typical Note:Dependent on microphone type |
RF Output |
|
| Antenna Type | Dual Band Helical |
| Occupied Bandwidth | <200 kHz |
| Channel-to-Channel Spacing | Standard Mode 350 kHz High Density Mode 125 kHz varies by region |
| Modulation Type | Shure Axient Digital Proprietary |
| Power | 2 mW, 10 mW, 40 mW See Frequency Range and Output Power table, varies by region |
| Specific Absorption Rate (SAR) | < 0.19 W/kg |
| SKU | ADX2 |
|---|---|
| Vikt (kg) | 0.050000 |
| EAN | 042406500654 |
| Tillverkare | Shure |
| Produktserie | Axient Digital |
| Produkttyp | Trådlös sändare |
| Frekvensområden | (470-636MHz) |
| Antall kanaler | 1 kanal |
| Kryptering | AES-256 |
