Shure P3TE - PSM300 Transmitter
Trådlös sändare inrymt i ett robust chassi av helt metall. P300 är Shure's instegsmodell för professionella In-Ear system.S8 (823-832MHz)
Kontakta en produktexpert om denna produkt
Pålitlig trådlös överföring och 24-bitars digitalt ljud kombinerar för att leverera en fantastisk personlig mix för varje prestanda.
P3T kan två ljudkanaler till en bodypack-mottagare upp till 90 meter bort, med patenterad Audio Reference Companding för att säkerställa transparent ljudkvalitet utan dippar eller bortfall.
- Transmitter sends a stereo or mono mix wirelessly to performers onstage
- One-touch IR sync on user-friendly front-panel controls instantly links transmitter to receiver
- Rear-panel ¼" (6.3 mm) TRS balanced inputs and loop outputs provide versatile connectivity to audio sources and other P3T units
- Up to 30 mW output power (regionally dependent)
- High-contrast LCD screen with left / right audio output meters
- Selectable line / aux level
- When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.
| RF Output Power | 10, 20, 30 mW Note: varies by region |
|---|---|
| RF Output Impedance | 50 Ω (typical) |
| Net Weight | 783 g (27.6oz.) |
| Dimensions | 43 × 198 × 172 mm (1.7 × 7.8 × 6.8 in.), H × W × D |
| Power Requirements | 12–15 V DC, 260 mA maximum |
Audio Input |
|
| Connector Type | 6.35 mm (1/4") TRS |
| Polarity | Tip positive with respect to ring |
| Configuration | Electronically balanced |
| Impedance | 40 kΩ (actual) |
| Nominal Input Level | Switchable, +4 dBu, -10 dBV |
| Maximum Input Level | +4 dBu: +22 dBu -10 dBV: +12.2 dBu |
| Pin Assignments | Tip=hot, Ring=cold, Sleeve=ground |
| Phantom Power Protection | Up to 60 V DC |
Audio Ouput |
|
| Connector Types | 6.35 mm (1/4") TRS |
| Configuration | Electronically balanced |
| Impedance | Connected directly to inputs |
| SKU | P3TE |
|---|---|
| Vikt (kg) | 3.447000 |
| EAN | 042406352932 |
| Tillverkare | Shure |
| Produktserie | PSM300 |
| Produkttyp | Trådlös sändare |
| Antall kanaler | 1 kanal |
| Tillkopling | Jack, BNC |
Pålitlig trådlös överföring och 24-bitars digitalt ljud kombinerar för att leverera en fantastisk personlig mix för varje prestanda.
P3T kan två ljudkanaler till en bodypack-mottagare upp till 90 meter bort, med patenterad Audio Reference Companding för att säkerställa transparent ljudkvalitet utan dippar eller bortfall.
- Transmitter sends a stereo or mono mix wirelessly to performers onstage
- One-touch IR sync on user-friendly front-panel controls instantly links transmitter to receiver
- Rear-panel ¼" (6.3 mm) TRS balanced inputs and loop outputs provide versatile connectivity to audio sources and other P3T units
- Up to 30 mW output power (regionally dependent)
- High-contrast LCD screen with left / right audio output meters
- Selectable line / aux level
- When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.
| RF Output Power | 10, 20, 30 mW Note: varies by region |
|---|---|
| RF Output Impedance | 50 Ω (typical) |
| Net Weight | 783 g (27.6oz.) |
| Dimensions | 43 × 198 × 172 mm (1.7 × 7.8 × 6.8 in.), H × W × D |
| Power Requirements | 12–15 V DC, 260 mA maximum |
Audio Input |
|
| Connector Type | 6.35 mm (1/4") TRS |
| Polarity | Tip positive with respect to ring |
| Configuration | Electronically balanced |
| Impedance | 40 kΩ (actual) |
| Nominal Input Level | Switchable, +4 dBu, -10 dBV |
| Maximum Input Level | +4 dBu: +22 dBu -10 dBV: +12.2 dBu |
| Pin Assignments | Tip=hot, Ring=cold, Sleeve=ground |
| Phantom Power Protection | Up to 60 V DC |
Audio Ouput |
|
| Connector Types | 6.35 mm (1/4") TRS |
| Configuration | Electronically balanced |
| Impedance | Connected directly to inputs |
| SKU | P3TE |
|---|---|
| Vikt (kg) | 3.447000 |
| EAN | 042406352932 |
| Tillverkare | Shure |
| Produktserie | PSM300 |
| Produkttyp | Trådlös sändare |
| Antall kanaler | 1 kanal |
| Tillkopling | Jack, BNC |
