Shure SLXD Portable ENG System without mic

Kontakta en produktexpert om denna produkt

RF INPUT
Dimensions (H × W × D)	4.21 × 2.68 × 1.0 in (107 × 68 × 25.3 mm)
Weight	1.8 lb (182 g)
Housing	Aluminum
Power Requirements Battery:	Rechargeable Li-Ion or 1.5 V AA batteries Power Supply: SBC-DC-903 Battery Eliminator, or 5 VDC via USB-C
Spurious Rejection	>75 dB Typical
Impedance	50 Ω
Phantom Power Protection	Yes
Antenna Type	1/4 Wave Whip
AUDIO OUTPUT
Audio Frequency Response	20 Hz – 20 kHz (+1, -3 dB)
Connector Type	1/8" (3.5 mm), ×2
Configuration	Balanced (Mono): Tip=audio +, Ring=audio –, Sleeve=ground Dual Mono: Tip = left, Ring = Right, Sleeve = Ground
Impedance (Camera)	Balanced (Mono) Line: 450 Ω Balanced (Mono) Mic: 240 Ω Dual Mono Line: 400 Ω Dual Mono Mic: 200 Ω
Full Scale Output	Camera (Balanced Line): 15 dBV Headphone: 13 mW @ 64 Ω Load

AUDIO INPUT
Battery Type	Rechargeable Li-Ion or 1.5 V AA batteries
Dimensions (Dia. × L)	4.9 × 1.6 × 1.6 in (126 × 41 × 41 mm)
Weight	7.0 oz. (200 g)
Housing	Aluminum, Zinc Alloy, PC/ABS
Configuration	XLR
Maximum Input Level 1 kHz @ 1% THD	Pad -12 dB: 20.5 dBV 0 dB: 8.5 dBV Boost +12 dB: -3.5 dBV Note: Dependent on Microphone Type
Phantom Power	+48 V (7 mA maximum) +12 V (15 mA maximum)
RF OUTPUT
Antenna Type	Dipole
Occupied Bandwidth	<200 kHz
Modulation Type	Shure Propietary Digital
Power	1 mW/10 mW/30 mW Varies by region. See Frequency Range and Output Power Table.
Specific Absorption Rate (SAR)	<0.17 W/kg

Mer information
SKU	SLXD35
Vikt (kg)	1.264000
Enhet	Stk
EAN	0042406763646
Tillverkare	Shure
Produktserie	SLX-D
Produkttyp	Trådlöst system
Antall kanaler	1 kanal
Kraftbehov	AA batterier (alkaline, lithium, eller laddbara NiMH), SB903 Lithium-Ion
Färg	Svart
